Feature:

Brand:HOTOOK

Product model:DFC/RB/F001

dimension:535(U)*465(W)*180(H)MM

IP level:IPX7


Share it:

skype:movsuns?chat
  • Features
  • Specification
  • Package

| Feature

This product solar pool cleaning robot uses the combination of lithium battery and solar charging to power the machine, while retaining the external charger fast charging mode, so that the machine can have good endurance and emergency ability; The machine's propulsion and rolling motor are brushless motors, which have high working efficiency and long service life. The machine has automatic obstacle avoidance and escape functions on the water surface, and has certain maneuverability and wall-sticking effect, so that all corners of the pool surface can be cleaned well.


| Founction

1. Adapter charging prompt function

When the ⑩ adapter charging port starts to charge, when the battery is not satisfied, the adapter charging prompt light will flash;

When the battery is fully charged, the adapter charging prompt light will be steady on and beep for one minute;

2. Power switch function

Press and hold the function button for 2-3 seconds. The indicator, motor, buzzer and other hardware will self-check, indicating that the cleaner enters the normal working state.

In the startup state, long press the function button for 2-3 seconds to shut down the cleaner;

3. Cleaning function

The left and right propulsion motor and the rolling brush will start, wherein the rolling brush will roll in a clockwise direction;

⑧ The left and right headlights of the machine;

4. Change the working mode

Press the function button (2) to switch between the quick cleaning mode and the normal cleaning mode, and the corresponding prompt light will also switch; Power on for normal cleaning mode;


| Product Parameter

Filtering Capability
860 SQ/FT(80㎡)
Rated Voltage
11.1V
Solar Panel Power
10W
Power
8W
Filtering Density
400μm
Cruising Ability
More than 6 hours
Movement Speed
5-10 meters/minute
IP Code
IPX7

Rated Input Voltage of the charger
100-240VAC

Rated Input Frequency of the Charger
50/60HZ
Rated Output Voltage of the Charger
12.6VDC
Rated Output Current of the Charger
1.0A
Motor Type
brushless
Battery Capacity
2500mAh
Charge Time
2-3 hours
Storage capacity
4.1L
Size
535(U)*465(W)*180(H)mm
Weight
4.8kg

-------

Solar Charging Battery Swimming Pool Robot Cleaner

Solar Charging Battery Swimming Pool Robot Cleaner

Solar Charging Battery Swimming Pool Robot Cleaner




Solar Charging Battery Pool Robot Cleaner

| FAQ

Q1:How to place an order?  What about prices?

A1:Please send an inquiry or contact with online service, after receiving your inquiry we will reply you with prices and information;  Or catalog with full prices, thank you.


Q2:What is your minimum order requirement ?

A2:Yes,to support your business, we accept sample order, trial order to test our products and your market.  thank you!


Q3:What is your payment terms?

A3:Paypal, western union,T/T, L/C, or Escrow, MoneyGram. Thank you.


Q4:Do you provide OEM,ODM,customized manufacturing service?

A4:Yes,we are a china soure factory manufacturer of pool light and swimming pool accesssories and swimming pool equipment,we warmly welcome your customized requirement, and we have more than 20 engineers who can realize youridea specifications on paper easily and turn them into the specific goods. We are sure to be your unique and reliablepartner of ODM/OEM business. Thank you!


Product model:DFC/RB/F001

Maximum cleaning area:860 SQ/FT (80 m)

Rated operating voltage:11.1 V

Solar panel power:10W

Rated power:8W

Filtration density:450um

Endurance:Over 180 minutes

Moving speed:5-10 m/min

Rated input voltage of charger:100-240VAC

IP level:IPX7

Rated input frequency of charger:50/60HZ

Pool water temperature:50F-95F(10C-35C)

Rated output voltage of the charger:12.6 VDC

Motor type:brushless

Rated output current of the charger:1.0 A

dimension:535(U)*465(W)*180(H)MM

Battery capacity:2500mAh

weight:4.8 kg

Charging time:2-3 hours

Storage temperature:-4 ~113 (-20C~45C)RHS75%
